Chapter 10. Setting The Design With Zend_View, Zend_Layout, HTML 5 and Yahoo! User Interface Library

[Important] Important

This is a draft chapter. Content may change and new sections be added in the coming days. Your feedback is, as always, welcome in the paragraph or chapter level comments including any criticism (more than welcome!) or suggestions for future updates to this chapter.

10.1. Introduction

In this chapter we will be creating a simple web design for our blog. Obviously this falls into the View layer of the Model-View-Controller (MVC) architectural design pattern. On a more basic level, it's primarily the HTML markup and CSS styling the blog will be using. Like many frameworks, all markup will be stored as templates in our application which are rendered at the end of any request and sent in a response to the user. It gets more interesting when you consider that a complex HTML page can be broken down into reusable or conditionally reusable elements. For example, every HTML page likely has reusable elements like a header, a footer, a navigation menu, a breadcrumb trail, etc. Alongside these elements are dynamic content and some other elements that are needed only for particular pages. In other places you need to apply special formatting rules, or insert formatted data from your database. Leveraging Zend Framework's templating via Zend_View can reduce duplicating all this markup and template processing from template to template by using View Helpers, Partials, Placeholders and Zend_Layout for the outermost common markup like the <head>, <title>, <html> and other elements including any CSS stylesheet links or Javascript files that need to be included.

I'm quite a bad web designer (sorry!) so for the our blog application I'll keep to a relatively simple design that someone else can supercharge later. The blog's markup will use HTML 5. HTML 5 is the next major revision of HTML so it seemed fitting to do some experimentation with the new standard. Since the XHTML 2.0 project has been shut down (at least for now) it's also the next major pseudo-replacement for XHTML. HTML 5, for the record, can technically be delivered as either an HTML or XML based serialisation (i.e. either text/html or application/xml+xhtml along with the syntax rules each implies). Given browser support (IE does not accept the XML content type), only the HTML serialisation is really viable though I will use XHTML conventions such as closing all tags and using lowercase attribute and tag names as much as possible since I am most familiar with those.

My use of HTML 5 should be considered experimental. It's not a final recommendation yet and not all browsers support it. You should be considering Firefox 3.5, Internet Explorer 8 or any other more recent browser version for use with HTML 5 - anything older will have patchy support. HTML 5 is, however, backwards compatible to a degree with HTML 4. It does need some coaxing with Internet Explorer when styling (IE doesn't recognise the new HTML 5 elements and can't style them - unlike other browsers) but we'll solve that later using a very neat and small javascript library, html5shiv.

To assist in styling, I will also be using the Yahoo User Interface (YUI) Library's CSS framework. I'll use this to normalise behaviour across all major browsers (i.e. font types, sizes, element spacing and margins, etc.). I will also use its grid implementation to setup page sections more easily. YUI CSS is only one of many CSS Frameworks. In the past I've used Elastic and Blueprint CSS. These frameworks are used primarily to save development time and write (hopefully) less CSS - an important factor for me since my design skills leave much to be desired and I could spend hours playing with CSS settings!

I really don't like editing too much CSS when I can entice a monkey with vast bags of peanuts to do a better job later on. That or a professional web designer (probably better than the monkey). For the moment I just need a nice default design which looks kind of okay in a pinch. In this article we're going to take a stab at setting up a default blog style, using some filler content, and finally capturing the design with Zend_View templates.

10.2. Zend_View: Object Oriented Templating

We PHP programmers have been using template engines since the dawn of PHP. In fact, PHP itself is a template engine and that was the original raison d'être for its entire existence - you can mix PHP into your HTML or other markup very easily. One thing we have not been great at is making a distinction between presentation (markup/formatting) and presentation logic (encapsulates logic for generating markup, formatting elements, or even accessing the Model). Mostly, the distinction has been to separate PHP from HTML which completely misses the point since you are only replacing PHP with a custom tag language. This strategy's sole redeeming factor is that it often prevents web designers from using PHP itself - a valid concern no doubt. PHP is a template engine so there is nothing wrong with mixing PHP and HTML. It's part and parcel of how PHP works. Doing it in a more deliberate manner as part of a templating system simply pushes us into doing it right.

Zend_View is the Zend Framework's template rendering solution which formalises the concept of separating presentation from presentation logic. It's an object oriented solution which does not use a tag based system (e.g. like that used by Smarty or Java's JavaServer Pages (JSP)). Templates rendered by Zend_View use PHP directly instead. At a higher level, Zend_View encapsulates an application's View, from MVC, which accepts user input and outputs a presentation of the application, whether it be HTML, XML, JSON, etc., based on any data it is either provided with or designed to independently retrieve. Technically Zend_View doesn't accept user input since this is handled in the Controller layer - there is some leakage between Views and Controllers in this respect once you use MVC for web applications rather than desktop applications given the nature of HTTP, and besides, the Controller is itself a presentation mechanic. It's strictly related to the current request and manages response construction and output.

The most important aspect of Zend_View templating is that it is object oriented. You may use absolutely any value type in a template: arrays, scalars, objects and even PHP resources. There is no intermediary tag system between you and the full power of PHP. Part of this OOP approach is that all templates are effectively executed within the variable scope of the current Zend_View instance. To explain this consider the following template.

  • <html>
  • <head><title>My Page</title></head>
  • <body>
  • <?php echo strtolower($this->myName) ?>
  • </body>
  • </html>

In this template we see that PHP is used directly. We also see a reference to $this - representing the current object instance. But the template is not an object! Where does this come from?

Templates are included into the Zend_View::_run() protected method when being rendered and output buffering is used to capture the evaluated content. So any template content is effectively treated as evaluated code within Zend_View::_run(), i.e. you can access class methods, properties (like the public Zend_View::$myName) and other features as if you were writing a method on Zend_View itself (which effectively you are!).

How does this influence our thinking about the View? Since all templates are essentially method calls (in one form or another) it stands to reason that templates are indirectly amenable to all the advantages offered by object oriented programming. Templates can be nested, repeated, refactored, and encapsulated in other objects (View Helpers) through composition. This becomes more evident once you meet several concepts offered by Zend_View: View Helpers, Placeholders and Layouts. It is also evident from our discussions so far regarding the role of the Model. As I noted in Chapter 3: The Model, Views can directly access and read from Models using View Helpers, without the need for any Controller code to manage that interaction.

10.2.1. Layouts

The concept of Layouts is implemented by Zend_Layout. A Layout is that part of your presentation which remains relatively static across many (or all) pages. In a standard HTML document, this would likely include the header, footer, navigation menu, and any other section common to many pages. Since these parts remain largely static, it's pointless duplicating it across every single page level template. It would be impossible to maintain, requiring countless other templates to be altered for any change. For this reason, we can use Zend_Layout to create a number of Layout templates, into which all other template output is injected. This ensures templates in the rest of the application need not concern themselves with a common layout - it's offloaded to Zend_Layout.

A simple Layout template could be:

  • <html>
  • <head>
  • <title>My Page</title>
  • </head>
  • <body>
  • <?php echo $this->layout()->content ?>
  • </body>
  • </html>

As we discussed in previous chapters, the Controller implements View rendering by default using the ViewHelper Action Helper. Zend_Layout registers a new Action Helper and a FrontController Plugin, Zend_Layout_Controller_Action_Helper_Layout and Zend_Layout_Controller_Plugin_Layout, which allow rendering of a layout and access to the Layout instance from Controllers respectively. We'll cover Helpers and Plugins in more detail later but they may implement a hook method which is called automatically by the FrontController after certain events occur, in this case a postDispatch() method which is called when a request is dispatched to a Controller. The output from the Controller matched View gets assigned to the Layout template's public $content property which we may in turn echo at any point in the Layout template, such as between the <body> tags in our example.

Zend_Layout also allows you to selectively disable layout rendering from Controllers, using the registered Action Helper. This is important when outputting something other than HTML, like JSON for example. Wrapping JSON or XML output in a HTML layout probably won't work in your favour. You can also swap layouts or set different layout variables from Controllers, so it's a very flexible system.

In terms of design patterns, Zend_Layout implements a loose form of Two Step View as described by Martin Fowler in Patterns Of Enterprise Application Architecture (POEAA). Fowler's definition of the Two Step View states:

Turns domain data into HTML in two steps: first by forming some kind of logical page, then rendering the logical page into HTML.

Obviously, in our case, the domain data is rendered immediately into HTML before being inserted into a specific point in the layout's HTML. The use of a Two Step View approach to layouts complements Zend_View's template composition approach as described below when using Partials.

You should also be aware that while Zend_Layout handles all the mechanics of layout assignments, the Layout template itself is rendered by an instance of Zend_View. So your Layouts may make full use of the typical Zend_View goodies like Partials, Placeholders and View Helpers. This can be something of a confusing point and may encourage a less than optimal solution I'll mention now.

One aspect of Zend_Layout to be careful with is that the Reference Guide mentions that Layouts and named response segments can be used in conjunction with the ActionStack Action Helper to create widgetised pages, i.e. each Action renders a View which is inserted into the template at its assigned point. There is an extremely important proviso to consider here - dispatching an action is an expensive task. As the name ActionStack suggests, this Action Helper creates a stack of Controller Actions to execute in turn requiring multiple dispatches of nearly the entire MVC framework. This should be avoided unless absolutely necessary. There is almost no reason to use the ActionStack since anything it achieves can be just as easily achieved using View Helpers at a fraction of the performance cost. Here's a blog post from Ryan Mauger explaining this in a bit more detail in Why the Zend Framework Actionstack is Evil. Note that this does not mean you should never use this aspect of Zend Framework but that you should have a very concrete need and have a tolerance for the inevitable performance hit.

10.2.2. Partials

Partials have a very simple use case. They are fragments of a higher level template which can be rendered, either once or repeatedly, at a specific point in the parent template. Partials may also be called "template fragments" to reflect this. A simple use case would be our blog's index page which may display a number of articles. The markup for each article is almost identical, differing only by the article text included. We could easily split this common article markup into a single partial, and loop through a collection of articles rendering each in turn. Besides reducing the amount of markup in a template, and offering a simple mechanism for looping through a data collection, they also afford some reusability. We could have article markup in the index page, the entry specific page, and several other locations. Using a partial isolates this repeated markup ensuring we can make global changes from a single location.

These template fragments, along with any other markup generating mechanism, form an implementation of the Composite View design pattern defined in the book, Core J2EE Patterns.

Use composite views that are composed of multiple atomic subviews. Each component of the template may be included dynamically into the whole and the layout of the page may be managed independently of the content.

An observation from our earlier examination of Layouts that I would make is that the Two Step View is itself a sub-pattern of the Composite View. In POEAA, Fowler skipped over a number of View related design patterns now in common use such as Composite View and View Helper which were instead formally defined in the Core J2EE Patterns book some time later.

Zend_View partials are implemented by the Zend_View_Helper_Partial and Zend_View_Helper_PartialLoop View Helpers. We cover View Helpers in the next section. The first helper renders a partial template once on every call and can be used either as a once off rendering or be embedded in a looping mechanism within the parent template. The second class specifically supports looping internally so that looping need not be embedded in the parent template.

The parameter passed to a partial may not be arbitrary, it must be an associative array or an object implementing a toArray() method. Otherwise it will be reduced to an array of object properties using get_object_vars(). From the resulting associative array, the keys are assigned as local class property names with their matching values assigned.

Consider the following example passing some minor data to a typical non-looping partial.

  • <?php echo $this->partial('article.phtml', array(
  • 'title'=>'Title',
  • 'content'=>'My Content!'
  • )) ?>

The article.phtml file is just like any other template except that it is only called as a partial. It would access the passed data as local class properties from it's own host Zend_View instance.

  • <article>
  • <h3><?php echo $this->escape($this->title) ?></h3>
  • <div class="content">
  • <?php echo $this->content ?>
  • </div
  • <article>

When using the partial loop helper, the parameter should be an array of items to loop through (each item following the same rules as a normal partial parameter) or any iterable object returning a valid partial parameter. As an example, the Zend_Db_Table_Rowset class is an iterable collection of objects of type Zend_Db_Table_Row. Each instance of Zend_Db_Table_Row implements a toArray() method. This means a rowset is a valid partial loop parameter.

For example, we could use our earlier partial by passing in an array of articles using the partial loop helper.

  • <?php echo $this->partialLoop('article.phtml', array(
  • array('title'=>'Title', 'content'=>'My Content!'),
  • array('title'=>'Title2', 'content'=>'More Content!')
  • )) ?>

Besides arrays, you can pass in objects directly and bypass the attempted casting of the object to an array. This is accomplished by setting an object key before calling the Zend_View::partial() or Zend_View::partialLoop() methods with any parameters. Remember that a parameterless call to a View Helper's primary method will usually just return the View Helper object for method chaining. For example:

  • <?php echo $this->partialLoop()->setObjectKey('article')
  • ->partialLoop($articleCollection) ?>

In the above example, all objects in the iterable Collection object (something we might implement in our domain model) are added to the partial template's host class as a public $article property. Within the partial we could do something like:

  • <article>
  • <h3><?php echo $this->escape($this->article->title) ?></h3>
  • <div class="content">
  • <?php echo $this->article->content ?>
  • </div>
  • </article>

This might not be the most brief example, afterall, using objects means the partial references are even longer. An array might be simpler but there are cases where using the object itself has benefits since a domain object may have lazy loaded references to other domain objects, like the Author of our Article in Chapter 9.

Partials have two other facets of importance. First, they operate in a separate variable scope from the parent template. This effectively means they are only aware of data specifically passed to them when calling the Zend_View::partial() or Zend_View::partialLoop() methods (these are mapped to Zend_View_Helper_Partial::partial() and Zend_View_Helper_Partial::partialLoop() respectively as that View Helper's primary method). They are not aware of any data set on the parent View from a controller or, if a second level nested fragment, the parent partial. This imposed restriction encourages a more object oriented approach to templating and prevents the leakage of data across multiple templates and template fragments (i.e. the problem which besets OOP designs employing global variables). This is simply good practice - we don't allow globals (hopefully) to contaminate the variable scope of our objects, so why should we allow the same for templates? All templates should be insulated from each other to prevent unwanted dependencies emerging that would make testing, maintenance and change more costly.

On a final note, you can nest a partial into another partial. You could have a whole tree of them if needed. It really depends on what your partial represents. A small slice of markup or a much larger part of a page template or layout. The nature of the template game is to compose a single view out of many constituent parts. How those parts are constructed or divided to prevent duplication of markup and encapsulate reusable functionality will depend on your needs.

10.2.3. View Helpers

If partials are the means of separating markup into reusable parcels, their presentation logic counterparts are View Helpers. A View Helper is used to create a reusable operation applied to a template. For example, imagine a partial has been passed a domain object representing a user comment. It contains a name, email, URL, some text and a date. The first four are easy, but how do you format the date for presentation? Your partial could include some PHP code to parse the date (depending on the date standard used), and recompose it into a desired readable form. But entries have published dates and even modified dates, so do comments. Will you repeat this PHP code everywhere?

This is obviously not a very maintainable solution. If something changes, and you need to reconfigure the parsing logic used, you could have lots of templates to edit. It would be far easier to encapsulate this PHP functionality as a View Helper, a reusable class that can be called from any template at any time. You could implement this as a ZFExt_View_Helper_FormatDate class (a custom helper), containing a formatDate() method to accept an arbitrary date and return a formatted form according to a specified pattern, like "YYYY-MM". This produces an easy to reuse class, which can benefit from unit testing and also be ported to other projects for reuse.

As I also discussed in Chapter 3: The Model, View Helpers can also be used to encapsulate a Model using, for example, the last chapter's implementation of a simple Data Mapper. Your helper can now query the domain model for some data, format it and add markup, and return the final result for immediate insertion at a template point. The primary concern with this approach is to always remember that a View Helper should never alter the domain model it interacts with - that is the concern of whatever Controller is handling user input. View Helpers are therefore a really useful feature. You can offload special formatting, menu generation, model querying and decoration with markup and a lot more to View Helpers.

View Helpers are also defined as a distinct pattern, as the View Helper design pattern, in the Core J2EE Patterns book.

All View Helpers follow a similar design. They implement a method with a name matching the class name, so ZFExt_View_Helper_FormatDate would define the method ZFExt_View_Helper_FormatDate::formatDate(). This "primary" method will usually accept parameters for the helper to operate on and return the results. For more complex helpers with many public methods, this primary method may also return the object itself. Since ZFExt_View_Helper_FormatDate would be a custom View Helper, you would also need to tell Zend_View where to find it, and what its class namespace is.

Let's consider a simple example. We've decided at the prompting of some analysis of our web page's loading performance to ensure that any javascript or css files can be cached by a client for extended periods. This is covered by the well documented Yahoo Performance Best Practices in the section Add an Expires or a Cache-Control Header. We therefore run off and configure Apache to use a far in the future Expires header when serving static files likes CSS or Javascript. We now find another problem - if the client caches these forever, how can we roll out changes and updates? A common strategy is to append a URI query string to the static file URIs which is updated in our markup whenever the referenced file changes. The cached resource uses the original URI (you can cache URIs with query strings if an explicit Expires header is sent), but when it changes the client will load from the new URI since the query string has changed, i.e. it's a new resource.

This would create a URI of the form: http://zfblog.tld/css/style.css?1185131970. The final query string is, very obviously, a timestamp representing the file modification date. You could just as easily use a version number. Let's write a View Helper which can automatically assign these query strings so that our updates alter their URIs on the fly without any manual intervention. Your custom helpers may extend from Zend_View_Helper_Abstract which offers some standard functionality if needed (we don't here).

  • <?php
  • class ZFExt_View_Helper_AppendModifiedDate extends Zend_View_Helper_Abstract
  • {
  • public function appendModifiedDate($file) {
  • $root = getcwd();
  • $filepath = $root . $file;
  • $mtime = filemtime($filepath);
  • return $file . '?' . $mtime;
  • }
  • }

The new View Helper is short and to the point. It accepts the relative path to a file on our server as normally used in markup, checks the file modified date, and appends that date as a timestamp to the path. The resulting path can then be passed to any other helper (e.g. the HeadLink or HeadScript View Helpers) or outputted directly into the relevant markup. Here's a template fragment using the new custom helper.

  • <link rel="stylesheet" href="<?php echo $this->appendModifiedDate('/css/style.css') ?>" type="text/css" media="screen" />

Besides writing custom helpers, the Zend Framework offers some standard View Helpers for common tasks like managing markup generation (e.g. form and head elements). We'll cover several of these soon which use one more feature of Zend_View called Placeholders.

10.2.4. Placeholders

Placeholders address a specific need in templating with Zend Framework. They allow templates to access a shared registry of data, regardless of their variable scope. This is very close to the Registry Pattern, which in Zend Framework is often implemented using Zend_Registry, but has a more specific use case here. Consider a scenario where you discover that a web page needs to use some specific piece of javascript loaded as early as possible. Your layout does not contain it since it's just not needed for everything. Placeholders can resolve this dilemma by allowing templates and partials to add values to a Placeholder, a key in this shared registry. When a parent template or layout is rendered, it can then render the Placeholder data at any point it specifies. For Javascript, this is handled by a specialised Placeholder implemented by Zend_View_Helper_HeadScript with which you can append, prepend, overwrite or set at a specific index any javascript you need from any sub-template before it is finally rendered in a layout.

Aside from offering a selection of specialised Placeholders like HeadLink, HeadMeta, etc, you can utilise the base Placeholder View Helper for any other data needing to be communicated across templates. Let's look at an example where we have a layout that can insert the output from a Placeholder. The layout offers a render point allowing any templates to change the text attached to a standard header.

  • <html>
  • <head>
  • <title>My Page</title>
  • </head>
  • <body>
  • <h1><?php echo $this->placeholder('pageHeader') ?></h1>
  • <?php echo $this->layout()->content ?>
  • </body>
  • </html>

We can now set this value from any other template (including partials).

  • <?php $this->placeholder('pageHeader')->set('About') ?>
  • <p>My name is Joe. Joe Bloggs.</p>

Unlike the more specific Placeholder implementations, the generic Placeholder helper can be used for any value. If it's a specific value following specific formatting rules you can subclass the general helper to also add this formatting when it's echoed into a template. For example, let's implement a custom View Helper to format a page header using HTML 5.

  • <?php
  • class ZFExt_View_Helper_PageHeader extends Zend_View_Helper_Placeholder
  • {
  • public function pageHeader()
  • {
  • return $this;
  • }
  • public function set($value)
  • {
  • parent::placeholder('pageHeader')->set($value);
  • }
  • public function __string()
  • {
  • return "<h1>" . (string) parent::placeholder('pageHeader') . "</h1>";
  • }
  • }

This is a very simple example which merely acts to create a concrete wrapper around the Placeholder container matching the key "pageHeader". It also encloses the page title value in <h1> tags. Here is our layout and page template using the new concrete Placeholder.

  • <html>
  • <head>
  • <title>My Page</title>
  • </head>
  • <body>
  • <?php echo $this->pageHeader() ?>
  • <?php echo $this->layout()->content ?>
  • </body>
  • </html>
  • <?php $this->pageHeader()->set('About') ?>
  • <p>My name is Joe. Joe Bloggs.</p>

10.2.5. Short Tags vs Full Tags

You may notice that throughout the book I show a preference for using full PHP tags, i.e. <?php (echo) ... ?>, in preference to short tags, <?(=) ... ?>. Short tags are an optional PHP setting. While many servers have them enabled to increase compatibility with applications utilising them, many stock servers will not since they are disabled in PHP's recommended configuration file, php.ini.recommended. In addition, we know that PHP 6 may deprecate short tags completely to resolve a conflict with XML declarations which use a similar form, <?xml ... ?>. Traditionally, XML declarations have to be echoed if generating XML from a template using short tags. Personally, I consider the probable PHP6 deprecation a nuisance. Writing <?php echo ... ?> more than a few times is plain annoying to me, then again since it is an optional setting, distributed applications should never use it anyway. In any case, it's better to stick with what definitely works now rather than risk it breaking later.

The Zend Framework has allowed short tags to be used, regardless of configuration, using a stream wrapper. This is enabled if the short tags option is disabled in your php.ini configuration file, i.e. the short_open_tag flag, and you have set the useStreamWrapper option to true. You can do this using the useStreamWrapper option key in your application.ini file or by calling Zend_View::setUseStreamWrapper() in your bootstrap. Using the stream wrapper will likely have a performance cost attached so if you really need short tags, it's better to just enable them in your PHP configuration.

10.3. The ZFBlog Application Setup

Setting up the new blog application is not horrendously difficult, just copy over the Hello World example to the blog application's project directory where you currently have the beginning of our application's domain model. It will make an excellent base to start with. You may wish to add a new local domain and Virtual Host specifically for the blog following the instructions from that chapter and the related appendix for setting up Apache Virtual Hosts. For the purposes of the book I'll be using the domain http://zfblog.tld.

There are no other changes required. The rest of the chapter will detail where to go from there.

10.4. Creating An Index Page With HTML 5

The index page of our blog will predictably be the page displaying a list of entries. Using HTML 5, let's start by looking at the opening HTML tags. Later we'll add styling and worry about adding more elements and information to the page. For the moment, we'll be editing /application/views/scripts/index/index.phtml.

  • <!DOCTYPE html>
  • <html>
  • <head>
  • <meta name="language" content="en" />
  • <meta charset="utf-8"/>
  • <title>Pádraic Bradys Blog</title>
  • <link href="http://yui.yahooapis.com/2.7.0/build/reset-fonts-grids/reset-fonts-grids.css" media="screen" rel="stylesheet" type="text/css" />
  • <link href="http://yui.yahooapis.com/2.7.0/build/base/base-min.css" media="screen" rel="stylesheet" type="text/css" />
  • <!--[if IE]><script type="text/javascript" src="http://html5shiv.googlecode.com/svn/trunk/html5.js"></script><![endif]-->
  • </head>

HTML 5 uses a simplified Doctype which pretty much simply states this is HTML. There is no versioning or other information attached or needed. As we are aware that we can set the Doctype used by Zend_View and any dependent components, we can print this in our template using the Zend_View_Helper_Doctype View Helper. The Zend Framework's support for HTML 5 extends as far as the Doctype which tells any dependent View Helpers to use HTML 4 style tags. In fact, HTML 5 can also be written in a similar way to XHTML, i.e. you can use lowercase tag and attribute names, enclose attribute values in quotes, close all tags, etc. This is my preferred method of writing HTML 5 since it feels cleaner and I don't need to depart too far from the XHTML I'm familiar with. Zend Framework therefore poses a minor problem - it doesn't distinguish between HTML 5 and XHTML 5 (HTML 5 written with XML rules of wellformedness). We'll solve this by writing a custom View Helper to add support for a XHTML5 Doctype.

As with any HTML/XHTML, the root element is <html>. It is immediately followed by a <head> element which contains any <link>, <meta>, <title> or <style> elements we need. These can be written in any typical style though, as I explained, I prefer the XHTML practice. HTML 5 does add one new feature here - a new attribute for a <meta> element called charset. This new attribute is intended as a simplified means of informing a parser what character encoding is used by the document, and therefore it's a valid replacement for the common use Content-Type <meta> element. Again, the Zend Framework does not support this as yet, so we will add a second custom View Helper to implement it.

You may notice that even though we can write all these tags outright into our templates, I keep referring to implementing them as View Helpers. This is good practice, since using the View Helpers allows other templates to modify what appears in <head> by appending, prepending or even overwriting what stylesheets, scripts, and meta information are initially set. You might foresee this as advantageous in situations where a particular page needs additional styling or a different set of javascript code not required for all pages.

I have also added two CSS stylesheets from the Yahoo User Interface framework. These are loaded directly from a Yahoo server so we don't need to store anything locally. The first of these is a minified version of three merged stylesheets: reset, fonts and grid. The first two ensure all major browsers are on the same page, eradicating various rendering differences each implements by default. There's nothing quite like trying to deal with the inconsistencies across browsers on simple default styling. The grid styles will be used later to create a column layout more easily. The second included stylesheet, base, imposes a standard foundation styling for all major elements out of the box. At this rate, I should have relatively little CSS to write other than what applies specifically to my preferred style for the blog.

Finally, we have included a Javascript file from the html5shiv project. This is a relatively simple piece of Javascript used to ensure Internet Explorer can recognise the new HTML 5 elements. Otherwise we would not be able to style them. This is only needed for Internet Explorer so we have wrapped this in a set of conditionals matching all versions of Internet Explorer but excluding any other browser.

Let's now add a Header section representing the page title and the upper navigation area.

  • <!DOCTYPE html>
  • <html>
  • <head>
  • <meta name="language" content="en" />
  • <meta charset="utf-8"/>
  • <title>Pádraic Brady's Blog</title>
  • <link href="http://yui.yahooapis.com/2.7.0/build/reset-fonts-grids/reset-fonts-grids.css" media="screen" rel="stylesheet" type="text/css" />
  • <link href="http://yui.yahooapis.com/2.7.0/build/base/base-min.css" media="screen" rel="stylesheet" type="text/css" />
  • <!--[if IE]><script type="text/javascript" src="http://html5shiv.googlecode.com/svn/trunk/html5.js"></script><![endif]-->
  • </head>
  • <body>
  • <header>
  • <h1><a href="/">Pádraic Brady's Blog</a></h1>
  • <nav>
  • <ul>
  • <li><a href="/">Home</a></li>
  • <li><a href="#">About</a></li>
  • <li><a href="#">Projects</a></li>
  • <li><a href="#">Contact</a></li>
  • </ul>
  • </nav>
  • </header>

With HTML 5, we can already see some of the new elements. Our Header section is now wrapped by the <header> tag which encloses our usual <h1> header title and also another new member, a <nav> element which encloses our upper navigation menu. Probably the nicest thing here, aside from the semantic meaning, is that we can do away with a ton of <div> elements using class attributes to tell us what they represent.

HTML 5 provides some definitions for these new elements:

header

The header element represents a group of introductory or navigational aids. A header element is intended to usually contain the section's heading (an h1–h6 element or an hgroup element), but this is not required. The header element can also be used to wrap a section's table of contents, a search form, or any relevant logos.

nav

The nav element represents a section of a page that links to other pages or to parts within the page: a section with navigation links. Not all groups of links on a page need to be in a nav element — only sections that consist of major navigation blocks are appropriate for the nav element. In particular, it is common for footers to have a list of links to various key parts of a site, but the footer element is more appropriate in such cases, and no nav element is necessary for those links.

Next up, we need the main body of the markup showing where we would render our blog entries, followed by the final footer section containing a copyright and credits where necessary.

  • <!DOCTYPE html>
  • <html>
  • <head>
  • <meta name="language" content="en" />
  • <meta charset="utf-8"/>
  • <title>Pádraic Brady's Blog</title>
  • <link href="http://yui.yahooapis.com/2.7.0/build/reset-fonts-grids/reset-fonts-grids.css" media="screen" rel="stylesheet" type="text/css" />
  • <link href="http://yui.yahooapis.com/2.7.0/build/base/base-min.css" media="screen" rel="stylesheet" type="text/css" />
  • <!--[if IE]><script type="text/javascript" src="http://html5shiv.googlecode.com/svn/trunk/html5.js"></script><![endif]-->
  • </head>
  • <body>
  • <header>
  • <h1><a href="/">Pádraic Brady's Blog</a></h1>
  • <nav>
  • <ul>
  • <li><a href="/">Home</a></li>
  • <li><a href="#">About</a></li>
  • <li><a href="#">Projects</a></li>
  • <li><a href="#">Contact</a></li>
  • </ul>
  • </nav>
  • </header>
  • <section>
  • <article>
  • <header>
  • <h2>One Day...Revisited</h2>
  • <p>Posted on <time datetime="2009-09-07">Tuesday, 08 September 2009</time></p>
  • </header>
  • <div>
  • <p>I forgot!</p>
  • <p>I already am writing a book!</p>
  • </div>
  • <footer>
  • <address>By Pádraic</address>
  • </footer>
  • </article>
  • <article>
  • <header>
  • <h2>One Day...</h2>
  • <p>Posted on <time datetime="2009-09-07">Monday, 07 September 2009</time></p>
  • </header>
  • <div>
  • <p>I will write a book</p>
  • </div>
  • <footer>
  • <address>By Pádraic</address>
  • </footer>
  • </article>
  • </section>
  • <footer>
  • <p>Copyright &copy; 2009 Pádraic Brady</p>
  • <p>Powered by <a href="http://www.survivethedeepend.com">ZFBlog
  • </a></p>
  • </footer>
  • </body>
  • </html>

Well, this is new! HTML 5 has added more new elements and this is startlingly obvious now. Many slot into places where we would expect to place <div> tags with a class attribute referring to the purpose of the <div>. In a typical barebones page, you might expect to simple enclose the content in <article> tags since the content is a single item. In our blog, however, we know each entry rendered on the page is a self-contained article so we use multiple <article> elements and wrap all of them in a single <section> element (there can also be many <section> elements if the page is divided further, and they can be nested - not unlike Docbook XML). Each article will also have a header and footer, and so we use the HTML 5 tags relevant for these cases. Finally, any reference to an author's details is enclosed within <address> tags. A bit of a confusing point, the <address> tag does not relate to a physical address - it's more relevant for a person's other details like their name, website, email, description, etc.

Let's look at the definitions from the HTML 5 specification for these new elements in HTML 5.

section

The section element represents a generic document or application section. A section, in this context, is a thematic grouping of content, typically with a heading, possibly with a footer.

article

The article element represents a section of a page that consists of a composition that forms an independent part of a document, page, application, or site. This could be a forum post, a magazine or newspaper article, a Web log entry, a user-submitted comment, an interactive widget, or any other independent item of content. An article element is "independent" in the sense that its contents could stand alone, for example in syndication, or as a interchangeable component on a user-configurable portal page.

footer

The footer element represents a footer for its nearest ancestor sectioning content. A footer typically contains information about its section such as who wrote it, links to related documents, copyright data, and the like. Contact information belongs in an address element, possibly itself inside a footer.

address

The address element represents the contact information for its nearest article or body element ancestor. If that is the body element, then the contact information applies to the document as a whole. The address element must not be used to represent arbitrary addresses (e.g. postal addresses), unless those addresses are in fact the relevant contact information.

time

The time element represents either a time on a 24 hour clock, or a precise date in the proleptic Gregorian calendar, optionally with a time and a time-zone offset. This element is intended as a way to encode modern dates and times in a machine-readable way so that user agents can offer to add them to the user's calendar. For example, adding birthday reminders or scheduling events.

On a brief note, the new <time> element is not without its problems. It's tied strictly to the Gregorian calendar so it cannot represent non-Gregorian dates from before its introduction. Since <time> was intended to replace the microformat <abbr> element in hCalendar, it's actually a failure since it can't represent historical dates. Hopefully HTML 5's final recommendation will fix this.

Open your browser and navigate to http://zfblog.tld. You should see the new template rendered with all the default YUI CSS styling applied.

Initial Blog Index Page

10.5. Extracting Static Markup Into A Layout

Now that we have an initial design, we need to identify what parts of this template are static, i.e. that will rarely change from page to page. A quick assessment is enough to see that for our index page, only the entries would be expected to change. We could have a variable number to display and their content will be updated regularly. Armed with this, we can reduce our index template to only include the parts that are dynamic - we'll encapsulate the rest momentarily into a layout.

Here's the revised template /application/views/scripts/index/index.phtml.

  • <article>
  • <header>
  • <h2>One Day...Revisited</h2>
  • </header>
  • <div>
  • <p>I forgot!</p>
  • <p>I already am writing a book!</p>
  • </div>
  • <footer>
  • <address>By Pádraic</address>
  • </footer>
  • </article>
  • <article>
  • <header>
  • <h2>One Day...</h2>
  • </header>
  • <div>
  • <p>I will write a book</p>
  • </div>
  • <footer>
  • <address>By Pádraic</address>
  • </footer>
  • </article>

Let's push the leftover markup into a new template, referred to as a Layout, in /application/views/layouts/default.phtml.

  • <!DOCTYPE html>
  • <html>
  • <head>
  • <meta name="language" content="en" />
  • <meta charset="utf-8"/>
  • <title>Pádraic Brady's Blog</title>
  • <link href="http://yui.yahooapis.com/2.7.0/build/reset-fonts-grids/reset-fonts-grids.css" media="screen" rel="stylesheet" type="text/css" />
  • <link href="http://yui.yahooapis.com/2.7.0/build/base/base-min.css" media="screen" rel="stylesheet" type="text/css" />
  • <!--[if IE]><script type="text/javascript" src="http://html5shiv.googlecode.com/svn/trunk/html5.js"></script><![endif]-->
  • </head>
  • <body>
  • <header>
  • <h1><a href="/">Pádraic Brady's Blog</a></h1>
  • <nav>
  • <ul>
  • <li><a href="/">Home</a></li>
  • <li><a href="#">About</a></li>
  • <li><a href="#">Projects</a></li>
  • <li><a href="#">Contact</a></li>
  • </ul>
  • </nav>
  • </header>
  • <section>
  • <?php echo $this->layout()->content ?>
  • </section>
  • <footer>
  • <p>Copyright © 2009 Pádraic Brady</p>
  • <p>Powered by <a href="http://www.survivethedeepend.com">ZFBlog
  • </a></p>
  • </footer>
  • </body>
  • </html>

You'll notice that we are now referencing a Zend_View method layout(). As we noted when discussing View Helpers, a View Helper's class name reflects its primary method which is typically used, at a minimum, to retrieve an instance of the View Helper object. In this case, we are retrieving an instance of Zend_View_Helper_Layout and printing whatever is contained in its public $content property.

To understand how our index template is pushed into the property, we need to understand that all rendering is, by default, handled by Controllers using the ViewRenderer Action Helper. This helper will render a template for the current Controller and Action into a response. Zend_Layout can then intercept the rendered response body and inject it in the layout template. Then the entire layout is rendered in turn to finally produce the entire page.

You should also note that Layouts, like all templates, are executed within the variable scope of a Zend_View object, so all View Helpers and Zend_View methods are still accessible from your Layouts.

To enable Zend_Layout, we also need to configure it for use. Typically this requires a call to the static method Zend_Layout::startMvc() following any configuration of the instance, however since we are using Zend_Application for our bootstrapping we simply need to define some configuration values for a Layout Resource in /config/application.ini. The two options needed, and added at the bottom of our "Standard Resource Options" section set the name of the layout template to use by default omitting the .phtml file extension. The second configures the path at which Layout templates can be located.

  • [production]
  • ; PHP INI Settings
  • phpSettings.display_startup_errors = 0
  • phpSettings.display_errors = 0
  • ; Bootstrap Location
  • bootstrap.path = APPLICATION_ROOT "/library/ZFExt/Bootstrap.php"
  • bootstrap.class = "ZFExt_Bootstrap"
  • ; Standard Resource Options
  • resources.frontController.controllerDirectory = APPLICATION_PATH "/controllers"
  • resources.view.encoding = "UTF-8"
  • resources.modifiedFrontController.contentType = "text/html;charset=utf-8"
  • resources.layout.layout = "default"
  • resources.layout.layoutPath = APPLICATION_PATH "/views/layouts"
  • ; HTML Markup Options
  • resources.view.doctype = "HTML5"
  • ; Autoloader Options
  • autoloaderNamespaces[] = "ZFExt_"
  • [staging : production]
  • [testing : production]
  • phpSettings.display_startup_errors = 1
  • phpSettings.display_errors = 1
  • resources.frontController.throwExceptions = 1
  • [development : production]
  • phpSettings.display_startup_errors = 1
  • phpSettings.display_errors = 1
  • resources.frontController.throwExceptions = 1

Returning to your browser, navigate to http://zfblog.tld and you should the exact same page as before with no differences. Our index template is now being rendered into the new Layout.

To complete the picture, let's also take this opportunity to edit the second page template in our application at /application/views/scripts/error/error.phtml. You'll notice that this is not enclosed in <article> tags since it's a generic message and not a standalone document article. I've also switched to using a second level header <h2> enclosed by a <header> element for the <article>.

  • <header>
  • <h2>An Error Has Occurred</h2>
  • </header>
  • <div>
  • <?php if ($this->statusCode == 500): ?>
  • <p>We're truly sorry, but we cannot complete your request at this
  • time.</p>
  • <p>If it's any consolation, we have scheduled a new appointment for our
  • development team leader in Torture Chamber #7 to encourage his colleagues
  • to investigate this incident.</p>
  • <?php else: ?>
  • <p>We're truly sorry, but the page you are trying to locate does not
  • exist.</p>
  • <p>Please double check the requested URL or consult your local
  • Optometrist.</p>
  • <?php endif; ?>
  • </div>

Go ahead and give it a test run, using an invalid URL like http://zfblog.tld/foo/bar. Remember that you will need to temporarily disable the throwing of Exceptions in application.ini to see the error page.

Initial Blog Error Page

10.6. Replacing Changeable Elements With Placeholders

Our Layout is now in place, however we can go further and ensure that page level templates, or even partials, can actually modify some parts of the Layout on demand, specifically in the area of stylesheets, page titles, javascript and meta tags. The Zend Framework can allow for such changes through the use of Placeholders, specifically a number of concrete implementations like Zend_View_Helper_HeadTitle, Zend_View_Helper_Doctype, etc. As mentioned earlier, Placeholders allow templates to add, remove, or even replace items within a self-contained data container, the contents of which are rendered into their final form either in an outer layer of the template hierarchy.

Let's start by modifying our Layout at /application/views/layouts/default.phtml to use several of these Placeholder View Helpers.

  • <?php echo $this->doctype() . "\n" ?>
  • <html>
  • <head>
  • <?php
  • echo $this->headMeta()->setIndent(' ') . "\n";
  • echo $this->headTitle('Pádraic Brady\'s Blog')
  • ->setSeparator(' / ')->setIndent(' ') . "\n";
  • echo $this->headLink()->setIndent(' ')
  • ->appendStylesheet('http://yui.yahooapis.com/2.7.0/build/reset-fonts-grids/reset-fonts-grids.css')
  • ->appendStylesheet('http://yui.yahooapis.com/2.7.0/build/base/base-min.css') . "\n ";
  • echo $this->headScript()->prependFile(
  • 'http://html5shiv.googlecode.com/svn/trunk/html5.js',
  • 'text/javascript',
  • array('conditional'=>'IE')) . "\n";
  • ?>
  • </head>
  • <body>
  • <header>
  • <h1><a href="/">Pádraic Brady's Blog</a></h1>
  • <nav>
  • <ul>
  • <li><a href="/">Home</a></li>
  • <li><a href="#">About</a></li>
  • <li><a href="#">Projects</a></li>
  • <li><a href="#">Contact</a></li>
  • </ul>
  • </nav>
  • </header>
  • <section>
  • <?php echo $this->layout()->content ?>
  • </section>
  • <footer>
  • <p>Copyright © 2009 Pádraic Brady</p>
  • <p>Powered by <a href="http://www.survivethedeepend.com">ZFBlog
  • </a></p>
  • </footer>
  • </body>
  • </html>

Zend_View_Helper_Doctype and Zend_View_Helper_HeadMeta are both echoed unchanged, except to add some standard indentation and newlines where appropriate. This merely ensures the markup source is easier to read. Rather than set any values within the Layout for these two, we will instead configure them from our bootstrap using options from application.ini.

Zend_View_Helper_HeadTitle is called to set a Title part "Pádraic Brady's Blog". You can set additional parts and they will be rendered within a <title> element separated by any separator you choose to set using Zend_View_Helper_HeadTitle::setSeparator(). The optional second argument to the primary method headTitle() can be set to "APPEND", the default, or "PREPEND" to ensure a title part is rendered at the start of the Title.

Zend_View_Helper_HeadLink can be used to append, prepend or replace stylesheet links. It also works for other generic links by passing an array of attributes and values to Zend_View_Helper_HeadLink::headLink(). Alternate links can be set using appendAlternate() and its siblings (prepend/set/offsetSetAlternate()). When adding stylesheets the optional parameters include setting the media and type attributes, and also setting an array of conditionals (such as we use in the next line for including a javascript file only for Internet Explorer). If you need to add a block of styles, this can be accomplished using Zend_View_Helper_Style instead. Finally, Zend_View_Helper_Script allows for the inclusion of scripts including javascript files.

You can note some of the similarities across these concrete Placeholder implementations. They have methods to set, append, and prepend items. Many also offer offsetSet*() methods to set items at a particular point in the array of items to render.

One piece of markup I've omitted is the charset <meta> tag. This cannot currently be rendered by the Zend Framework, but we'll solve this in the next section. For now, let's make some changes to our ZFExt_Bootstrap::_initView() method to configure the meta tags and Doctype to be rendered.

  • <?php
  • class ZFExt_Bootstrap extends Zend_Application_Bootstrap_Bootstrap
  • {
  • // ...
  • protected function _initView()
  • {
  • $options = $this->getOptions();
  • $config = $options['resources']['view'];
  • if (isset($config)) {
  • $view = new Zend_View($config);
  • } else {
  • $view = new Zend_View;
  • }
  • if (isset($config['doctype'])) {
  • $view->doctype($config['doctype']);
  • }
  • if (isset($config['language'])) {
  • $view->headMeta()->appendName('language', $config['language']);
  • }
  • $viewRenderer = Zend_Controller_Action_HelperBroker::getStaticHelper(
  • 'ViewRenderer'
  • );
  • $viewRenderer->setView($view);
  • return $view;
  • }
  • // ...
  • }

We can now modify application.ini to add at least one piece of meta information, the page's language. This is not a standard Zend_View configuration value, just a default we impose from our bootstrap class when setting meta information for the page.

  • [production]
  • ; PHP INI Settings
  • phpSettings.display_startup_errors = 0
  • phpSettings.display_errors = 0
  • ; Bootstrap Location
  • bootstrap.path = APPLICATION_ROOT "/library/ZFExt/Bootstrap.php"
  • bootstrap.class = "ZFExt_Bootstrap"
  • ; Standard Resource Options
  • resources.frontController.controllerDirectory = APPLICATION_PATH "/controllers"
  • resources.view.encoding = "UTF-8"
  • resources.modifiedFrontController.contentType = "text/html;charset=utf-8"
  • resources.layout.layout = "default"
  • resources.layout.layoutPath = APPLICATION_PATH "/views/layouts"
  • ; Autoloader Options
  • autoloaderNamespaces[] = "ZFExt_"
  • ; HTML Markup Options
  • resources.view.doctype = "HTML5"
  • resources.view.language = "en"
  • [staging : production]
  • [testing : production]
  • phpSettings.display_startup_errors = 1
  • phpSettings.display_errors = 1
  • resources.frontController.throwExceptions = 1
  • [development : production]
  • phpSettings.display_startup_errors = 1
  • phpSettings.display_errors = 1
  • resources.frontController.throwExceptions = 1

10.7. Improving HTML 5 Support With Custom View Helpers

For the moment at least, Zend Framework support for HTML 5 does not extend beyond offering an HTML Doctype. The Doctype used is actually important, not simply because it renders at the top of our Layout but because it determines how tags are constructed by a number of View Helpers. As I said before, I prefer an XHTML style approach to HTML 5 with closed tags, lowercase attribute names, and attribute values enclosed in quotes, among other facets. HTML 5 itself is relatively agnostic to these details, indeed it defines an XML serialisation as an alternate to the typical HTML variant.

With our Doctype set to "HTML5" this is problematic because when testing for XHTML, View Helpers check whether the Doctype name starts with "XHTML". HTML5 (our current Doctype option value) does not. To resolve this we should add a custom implementation of the standard Zend_View_Helper_Doctype (a simple subclass is all that's needed) to add support for an option called "XHTML5" which will ensure XHTML rules are applied to any output from View Helpers where they apply.

We'll store this custom View Helper at /library/ZFExt/View/Helper/Doctype.php. In order for our application to tell Zend_View where to find these custom helpers, we can define some new application.ini options in our "Standard Resource Options" section. These will provide a new path where custom View Helpers can be found, and the class prefix they use. We need no additional changes thereafter - custom View Helpers which reflect the name of any Zend Framework View Helper (i.e. they end with the same camel cased term) override the framework's helpers. So calling Zend_View::doctype() would now first check for a custom View Helper of that name.

  • [production]
  • ; PHP INI Settings
  • phpSettings.display_startup_errors = 0
  • phpSettings.display_errors = 0
  • ; Bootstrap Location
  • bootstrap.path = APPLICATION_ROOT "/library/ZFExt/Bootstrap.php"
  • bootstrap.class = "ZFExt_Bootstrap"
  • ; Standard Resource Options
  • resources.frontController.controllerDirectory = APPLICATION_PATH "/controllers"
  • resources.view.encoding = "UTF-8"
  • resources.modifiedFrontController.contentType = "text/html;charset=utf-8"
  • resources.layout.layout = "default"
  • resources.layout.layoutPath = APPLICATION_PATH "/views/layouts"
  • resources.view.helperPath = "ZFExt/View/Helper/"
  • resources.view.helperPathPrefix = "ZFExt_View_Helper_"
  • ; Autoloader Options
  • autoloaderNamespaces[] = "ZFExt_"
  • ; HTML Markup Options
  • resources.view.doctype = "HTML5"
  • resources.view.language = "en"
  • [staging : production]
  • [testing : production]
  • phpSettings.display_startup_errors = 1
  • phpSettings.display_errors = 1
  • resources.frontController.throwExceptions = 1
  • [development : production]
  • phpSettings.display_startup_errors = 1
  • phpSettings.display_errors = 1
  • resources.frontController.throwExceptions = 1

Implementing this new View Helper has a single goal - to allow for a new Doctype of XHTML5 which outputs the standard HTML5 doctype is echoed in a template. Any retrieval of the Doctype should also return the correct value which passes the XHTML test used by other View Helpers. If you followed the setting up of a new AllTests.php file for the domain model tests earlier, you can repeat that process for any custom View Helpers we intend adding. Here are our unit tests for such an implementation stored at /tests/ZFExt/View/Helper/DoctypeTest.php.

  • <?php
  • class ZFExt_View_Helper_DoctypeTest extends PHPUnit_Framework_TestCase
  • {
  • protected $helper = null;
  • public function setup()
  • {
  • $this->helper = new ZFExt_View_Helper_Doctype;
  • }
  • public function testRendersHtml5DoctypeForXhtmlSerialisation()
  • {
  • $this->helper->doctype('XHTML5');
  • $this->assertEquals('<!DOCTYPE html>', (string) $this->helper);
  • }
  • public function testReturnsXhtmlDoctypeName()
  • {
  • $this->helper->doctype('XHTML5');
  • $this->assertEquals('XHTML5', $this->helper->getDoctype());
  • }
  • }

Implementing this requires a simple subclass at /library/ZFExt/View/Helper/Doctype.php.

  • <?php
  • class ZFExt_View_Helper_Doctype extends Zend_View_Helper_Doctype
  • {
  • const XHTML5 = 'XHTML5';
  • public function __construct()
  • {
  • parent::__construct();
  • $this->_registry['doctypes'][self::XHTML5] = '<!DOCTYPE html>';
  • }
  • public function doctype($doctype = null)
  • {
  • if (null !== $doctype && $doctype == self::XHTML5) {
  • $this->setDoctype($doctype);
  • } else {
  • parent::doctype($doctype);
  • }
  • return $this;
  • }
  • }

As you can see from the class, except for any specific handling of XHTML5, we just hand control back to the parent class for all other possible Doctypes.

Another facet of HTML 5 support we can tackle is the new charset attribute that be used in a <meta> tag. Effectively this is used to replace:

  • <meta http-equiv="Content-Type" content="text/html; charset=utf-8"/>

With a shorter form which doesn't assert a Content-Type. Of course, you can still add the Content-Type if you need to but the web application should be served under the correct type anyway.

  • <meta charset="utf-8"/>

Unfortunately Zend_View_Helper_HeadMeta, the View Helper responsible for allowing templates and Layouts to add meta information does not recognise the charset attribute as valid. We can persuade it otherwise by adding another custom View Helper, again overriding the original class. Once more we'll subclass the original to minimise the code we need to write.

Here are the relevant unit tests stored at /tests/ZFExt/View/Helper/HeadMetaTest.php.

  • <?php
  • class ZFExt_View_Helper_HeadMetaTest extends PHPUnit_Framework_TestCase
  • {
  • protected $helper = null;
  • protected $view = null;
  • public function setup()
  • {
  • foreach (array(Zend_View_Helper_Placeholder_Registry::REGISTRY_KEY, 'Zend_View_Helper_Doctype') as $key) {
  • if (Zend_Registry::isRegistered($key)) {
  • $registry = Zend_Registry::getInstance();
  • unset($registry[$key]);
  • }
  • }
  • /**
  • * This custom helper only concerns (X)HTML 5 support
  • * using the ZFExt doctype helper for the XHTML flavour
  • */
  • $this->view = new Zend_View();
  • $this->view->addHelperPath('ZFExt/View/Helper', 'ZFExt_View_Helper');
  • $this->helper = new ZFExt_View_Helper_HeadMeta();
  • $this->helper->setView($this->view);
  • }
  • public function testRendersHtml5CharsetMetaElement()
  • {
  • $this->view->doctype('HTML5');
  • $this->helper->setCharset('utf-8');
  • $this->assertEquals('<meta charset="utf-8">', (string) $this->helper);
  • }
  • public function testRendersXhtml5CharsetMetaElement()
  • {
  • $this->view->doctype('XHTML5');
  • $this->helper->setCharset('utf-8');
  • $this->assertEquals('<meta charset="utf-8"/>', (string) $this->helper);
  • }
  • }

The implementation is a little more involved than usual since we are adding support for a whole other <meta> tag type not present previously. The new class is written to /library/ZFExt/View/Helper/HeadMeta.php.

  • <?php
  • class ZFExt_View_Helper_HeadMeta extends Zend_View_Helper_HeadMeta
  • {
  • protected $_typeKeys = array('name', 'http-equiv', 'charset');
  • public function setCharset($charset)
  • {
  • $item = new stdClass;
  • $item->type = 'charset';
  • $item->charset = $charset;
  • $item->content = null;
  • $item->modifiers = array();
  • $this->set($item);
  • return $this;
  • }
  • protected function _isValid($item)
  • {
  • if ((!$item instanceof stdClass)
  • || !isset($item->type)
  • || !isset($item->modifiers))
  • {
  • return false;
  • }
  • $doctype = $this->view->doctype()->getDoctype();
  • if (!isset($item->content)
  • && (($doctype !== 'HTML5' && $doctype !== 'XHTML5')
  • || (($doctype == 'HTML5' || $doctype == 'XHTML5') && $item->type !== 'charset'))
  • ) {
  • return false;
  • }
  • return true;
  • }
  • public function itemToString(stdClass $item)
  • {
  • if (!in_array($item->type, $this->_typeKeys)) {
  • require_once 'Zend/View/Exception.php';
  • throw new Zend_View_Exception(sprintf('Invalid type "%s" provided for meta', $item->type));
  • }
  • $type = $item->type;
  • $modifiersString = '';
  • foreach ($item->modifiers as $key => $value) {
  • if (!in_array($key, $this->_modifierKeys)) {
  • continue;
  • }
  • $modifiersString .= $key . '="' . $this->_escape($value) . '" ';
  • }
  • if ($this->view instanceof Zend_View_Abstract) {
  • if ($this->view->doctype()->getDoctype() == 'XHTML5'
  • && $type == 'charset') {
  • $tpl = '<meta %s="%s"/>';
  • } elseif ($this->view->doctype()->getDoctype() == 'HTML5'
  • && $type == 'charset') {
  • $tpl = '<meta %s="%s">';
  • } elseif ($this->view->doctype()->isXhtml()) {
  • $tpl = '<meta %s="%s" content="%s" %s/>';
  • } else {
  • $tpl = '<meta %s="%s" content="%s" %s>';
  • }
  • } else {
  • $tpl = '<meta %s="%s" content="%s" %s/>';
  • }
  • $meta = sprintf(
  • $tpl,
  • $type,
  • $this->_escape($item->$type),
  • $this->_escape($item->content),
  • $modifiersString
  • );
  • return $meta;
  • }
  • }

Don't worry if this all looks incomprehensible! We'll cover some application specific View Helpers in later chapters but, for the moment, we just need these two custom helpers to ensure we have fuller HTML 5 support at our fingertips.

In the class above we're replacing two original methods: _isValid() and itemToString(). The first validates the details of some meta information we want to render in a <meta> tag. The data is stored as an instance of stdClass, i.e. it's a simple data container that could just as easily have been an array. The main validation addition I made was to allow a new meta type of "charset" if the Doctype was one of the HTML 5 types. In the itemToString() method I added the capability to compose this new meta type into a <meta> tag, closing the tag if the Doctype used was XHTML5.

I also added a new method, setCharset() so creating this new tag is differentiated from the original two meta types supported, i.e. simple name/value types and http-equiv types.

With our new HTML 5 support completed, let's revisit application.ini and add a new HTML Markup Option called "charset" along with the new Doctype. Really, we could just use the Zend_View setting for character encoding but I decided to keep them separate so we could conditionally add the new meta tag type only if its specific option was set.

  • [production]
  • ; PHP INI Settings
  • phpSettings.display_startup_errors = 0
  • phpSettings.display_errors = 0
  • ; Bootstrap Location
  • bootstrap.path = APPLICATION_ROOT "/library/ZFExt/Bootstrap.php"
  • bootstrap.class = "ZFExt_Bootstrap"
  • ; Standard Resource Options
  • resources.frontController.controllerDirectory = APPLICATION_PATH "/controllers"
  • resources.view.encoding = "UTF-8"
  • resources.view.helperPath = "ZFExt/View/Helper/"
  • resources.view.helperPathPrefix = "ZFExt_View_Helper_"
  • resources.modifiedFrontController.contentType = "text/html;charset=utf-8"
  • resources.layout.layout = "default"
  • resources.layout.layoutPath = APPLICATION_PATH "/views/layouts"
  • ; Autoloader Options
  • autoloaderNamespaces[] = "ZFExt_"
  • ; HTML Markup Options
  • resources.view.charset = "utf-8"
  • resources.view.doctype = "XHTML5"
  • resources.view.language = "en"
  • [staging : production]
  • [testing : production]
  • phpSettings.display_startup_errors = 1
  • phpSettings.display_errors = 1
  • resources.frontController.throwExceptions = 1
  • [development : production]
  • phpSettings.display_startup_errors = 1
  • phpSettings.display_errors = 1
  • resources.frontController.throwExceptions = 1

We can now also amend the bootstrap class _initView() method to follow up and use the new charset option.

  • <?php
  • class ZFExt_Bootstrap extends Zend_Application_Bootstrap_Bootstrap
  • {
  • // ...
  • protected function _initView()
  • {
  • $options = $this->getOptions();
  • $config = $options['resources']['view'];
  • if (isset($config)) {
  • $view = new Zend_View($config);
  • } else {
  • $view = new Zend_View;
  • }
  • if (isset($config['doctype'])) {
  • $view->doctype($config['doctype']);
  • }
  • if (isset($config['language'])) {
  • $view->headMeta()->appendName('language', $config['language']);
  • }
  • if (isset($config['charset'])) {
  • $view->headMeta()->setCharset($config['charset'], 'charset');
  • }
  • $viewRenderer = Zend_Controller_Action_HelperBroker::getStaticHelper(
  • 'ViewRenderer'
  • );
  • $viewRenderer->setView($view);
  • return $view;
  • }
  • // ...
  • }

Go ahead now and reload the blog's index page. If you check the source code, it should now be completely in line with the original markup we introduced at the start of the chapter.

10.8. Adding A Link To A Custom Stylesheet

Our use of the YUI CSS framework has supplied us with a baseline style for the blog which is very basic but agreeable across all major browsers. We can supplement this with our own customised styles to provide the blog with a more well rounded look.

To achieve this we need to make a change so that our Layout template also includes a style.css file stored at /public/css/style.css. Into this file we can place additional CSS rules. Here's the revised <head> section of the altered layout.

  • <?php echo $this->doctype() . "\n" ?>
  • <html>
  • <head>
  • <?php
  • echo $this->headMeta()->setIndent(' ') . "\n";
  • echo $this->headTitle('Pádraic Brady\'s Blog')
  • ->setSeparator(' / ')->setIndent(' ') . "\n";
  • echo $this->headLink()->setIndent(' ')
  • ->appendStylesheet('http://yui.yahooapis.com/2.7.0/build/reset-fonts-grids/reset-fonts-grids.css')
  • ->appendStylesheet('http://yui.yahooapis.com/2.7.0/build/base/base-min.css')
  • ->appendStylesheet('/css/style.css') . "\n ";
  • echo $this->headScript()->prependFile(
  • 'http://html5shiv.googlecode.com/svn/trunk/html5.js',
  • 'text/javascript',
  • array('conditional'=>'IE')) . "\n";
  • ?>
  • </head>

Bearing in mind that we may take the Yahoo Performance Best Practices into consideration, let's formally add our previous View Helper example into the mix with a few changes. Here's the actual unit tests utilised by the custom helper ZFExt_View_Helper_IncludeModifiedDate. They utilise an empty style.css file you can put at /tests/ZFExt/View/Helper/_files/style.css to get a modified date. The tests are stored at /tests/ZFExt/View/Helper/IncludeModifiedDateTest.php. As with all these tests, add them to the closest AllTests.php file to run from PHPUnit. The only tricky part is managing the working directory PHP is currently using so a relative URI makes sense in the test and hits our style.css file correctly.

  • <?php
  • class ZFExt_View_Helper_IncludeModifiedDateTest extends PHPUnit_Framework_TestCase
  • {
  • protected $helper = null;
  • private $cwd = null;
  • public function setup()
  • {
  • $this->helper = new ZFExt_View_Helper_IncludeModifiedDate;
  • $this->cwd = getcwd();
  • chdir(dirname(__FILE__));
  • }
  • public function teardown()
  • {
  • chdir($this->cwd);
  • }
  • public function testAddsTimestampToFilenameBeforeFileExtension()
  • {
  • $file = '/_files/style.css';
  • $timestamped = $this->helper->includeModifiedDate($file);
  • $this->assertTrue((bool) preg_match("/^\/_files\/style\.\d{10,}\.css\$/", $timestamped));
  • }
  • public function testAddsTimestampToFilenameBeforeFileExtensionWithUriQueryString()
  • {
  • $file = '/_files/style.css?version=2.0';
  • $timestamped = $this->helper->includeModifiedDate($file);
  • $this->assertTrue((bool) preg_match("/^\/_files\/style\.\d{10,}\.css\?version=2\.0$/", $timestamped));
  • }
  • }

As you can probably notice, we've beefed up the helper to handle an additional case where a file URI may already include a query string of some type already. This time it also adds the modification timestamp within the filename instead of the query string. This handles a scenario where many proxies ignore the query string when caching files, so changing the filename or path is far more effective. Of course we do not physically change the filename - instead we'll add a new rewrite rule to /public/.htaccess so any URIs to physical files of the form /name.timestamp.extension (e.g. /style.1252108229.css) are remapped to the actual filename correctly. Here's the implementation stored at /library/ZFExt/View/Helper/IncludeModifiedDate.php.

  • <?php
  • class ZFExt_View_Helper_IncludeModifiedDate extends Zend_View_Helper_Abstract
  • {
  • public function includeModifiedDate($uri) {
  • $parts = parse_url($uri);
  • $root = getcwd();
  • $mtime = filemtime($root . $parts['path']);
  • return preg_replace(
  • "/(\.[a-z0-9]+)(\?*.*)$/",
  • '.'.$mtime.'$1$2',
  • $uri
  • );
  • }
  • }

The following change adds support for this style of timestamping files to /public/.htaccess, so we do load the underlying file which doesn't have a timestamp included in its name. The rewrite rule merely removes the timestamp part of the incoming filename. You can add in additional file extensions or directories this applies to as needed. I've assumed some reasonable common defaults.

SetEnv APPLICATION_ENV development

RewriteEngine On

RewriteRule ^(scripts|css|images)/(.+)\.(.+)\.(js|css|jpg|gif|png)$ $1/$2.$4 [L]

RewriteCond %{REQUEST_FILENAME} -s [OR]
RewriteCond %{REQUEST_FILENAME} -l [OR]
RewriteCond %{REQUEST_FILENAME} -d

RewriteRule ^.*$ - [NC,L]
RewriteRule ^.*$ /index.php [NC,L]

Our layout template can now utilise the new custom helper as follows.

  • <?php echo $this->doctype() . "\n" ?>
  • <html>
  • <head>
  • <?php
  • echo $this->headMeta()->setIndent(' ') . "\n";
  • echo $this->headTitle('Pádraic Brady\'s Blog')
  • ->setSeparator(' / ')->setIndent(' ') . "\n";
  • echo $this->headLink()->setIndent(' ')
  • ->appendStylesheet('http://yui.yahooapis.com/2.7.0/build/reset-fonts-grids/reset-fonts-grids.css')
  • ->appendStylesheet('http://yui.yahooapis.com/2.7.0/build/base/base-min.css')
  • ->appendStylesheet($this->includeModifiedDate('/css/style.css')) . "\n ";
  • echo $this->headScript()->prependFile(
  • 'http://html5shiv.googlecode.com/svn/trunk/html5.js',
  • 'text/javascript',
  • array('conditional'=>'IE')) . "\n";
  • ?>
  • </head>

We won't use the View Helper with any of the YUI CSS URIs since they already have a built in reference to a version number. We can change the URIs manually as new version of the CSS framework are released, all from the layout template, without necessitating any other changes. Keeping track of our layout markup, here's what the browser output source looks like at this point for our <head> section:

  • <!DOCTYPE html>
  • <html>
  • <head>
  • <meta name="language" content="en" />
  • <meta charset="utf-8"/>
  • <title>Pádraic Bradys Blog</title>
  • <link href="http://yui.yahooapis.com/2.7.0/build/reset-fonts-grids/reset-fonts-grids.css" media="screen" rel="stylesheet" type="text/css" />
  • <link href="http://yui.yahooapis.com/2.7.0/build/base/base-min.css" media="screen" rel="stylesheet" type="text/css" />
  • <link href="/css/style.1252108229.css" media="screen" rel="stylesheet" type="text/css" />
  • <!--[if IE]> <script type="text/javascript" src="http://html5shiv.googlecode.com/svn/trunk/html5.js"></script><![endif]-->
  • </head>

As you can see, the style.css URI now has a modified date attached in the query string as we would expect.

If you were wondering how to accomplish the use of the Expires and Cache-Control headers in practice, it's usually done from your Virtual Host configuration. You will need to enable the Apache mod_expires Module in your web server's configuration beforehand.

Here's a sample configuration of the blog's Virtual Host implementing an Expires header of six months from the first time a client accesses a static file. I've added two rules to illustrate the options - setting by matching files to a regular expression or by explicitly referring to the type the header should be applied to. The rules are embedded in a conditional so they are ignored if the required Module is not loaded in Apache. It is also essential to remember that unless you use a modified date/hash query string for a resource's URI, the client will cache these resources for six months and never retrieve updates during that time unless they lose their cache or force a complete reload (e.g. using CTRL+SHIFT+R in Firefox).

<VirtualHost *:80>
    ServerName zfblog.tld
    DocumentRoot /home/padraic/projects/zfblog/public

    <Directory "/home/padraic/projects/zfblog/public">
        Options Indexes MultiViews FollowSymLinks
        AllowOverride all
        Order deny,allow
        Allow from all

        <IfModule mod_expires.c>
            ExpiresActive on
            <FilesMatch "\.(ico|jpg|jpeg|png|gif)$">
                ExpiresDefault "access plus 6 months"
            </FilesMatch>
            ExpiresByType text/css "access plus 1 year"
            ExpiresByType text/javascript "access plus 1 year"
        </IfModule>

    </Directory>

</VirtualHost>

Utilising this configuration will cause all the matching file types to be sent to a client with two new headers. For example:

Cache-Control: max-age=31536000
Expires: Sun, 05 Sep 2010 00:39:27 GMT

Expires indicates a date six months away on which the file should be deemed as expired and requested once again from the server, and the second, Cache-Control, indicates the maximum life of the resource in seconds. At a technical level, the Cache-Control header is the most important since in most cases it actually overrides the Expires header. You can also set this up from your .htaccess file using the same set of rules.

10.9. Customising The Style

Before we hit the custom style sheet, let's first make use of what we've already include with the Yahoo User Interface CSS. The following set of changes to our default layout template at /application/views/layouts/default.phtml will add a typical website layout with header, footer, main body and a left handed column for any additional navigation links or complementary content.

  • <?php echo $this->doctype() . "\n" ?>
  • <html>
  • <head>
  • <?php
  • echo $this->headMeta()->setIndent(' ') . "\n";
  • echo $this->headTitle('Pádraic Brady\'s Blog')
  • ->setSeparator(' / ')->setIndent(' ') . "\n";
  • echo $this->headLink()->setIndent(' ')
  • ->appendStylesheet('http://yui.yahooapis.com/2.7.0/build/reset-fonts-grids/reset-fonts-grids.css')
  • ->appendStylesheet('http://yui.yahooapis.com/2.7.0/build/base/base-min.css')
  • ->appendStylesheet($this->includeModifiedDate('/css/style.css')) . "\n ";
  • echo $this->headScript()->prependFile(
  • 'http://html5shiv.googlecode.com/svn/trunk/html5.js',
  • 'text/javascript',
  • array('conditional'=>'IE')) . "\n";
  • ?>
  • </head>
  • <body>
  • <div id="doc" class="yui-t1">
  • <header id="hd" role="banner">
  • <hgroup>
  • <h1><a href="/">Pádraic Brady's Blog</a></h1>
  • <h2>Musings On PHP And Zend Framework</h2>
  • </hgroup>
  • <nav role="navigation">
  • <ul>
  • <li><a href="/">Home</a></li>
  • <li><a href="#">About</a></li>
  • <li><a href="#">Projects</a></li>
  • <li><a href="#">Contact</a></li>
  • </ul>
  • </nav>
  • </header>
  • <div id="bd">
  • <div id="yui-main">
  • <div class="yui-b" role="main">
  • <section id ="content" class="yui-g">
  • <?php echo $this->layout()->content ?>
  • </section>
  • </div>
  • </div>
  • <section class="yui-b">
  • <nav role="navigation" aria-labelledby="leftnav-label">
  • <h2 id="leftnav-label">External Links</h2>
  • <ul>
  • <li><a href="#">Survive The Deep End</a></li>
  • <li><a href="#">Zend Framework</a></li>
  • <li><a href="#">Planet-PHP</a></li>
  • <li><a href="#">I'm on Twitter!</a></li>
  • </ul>
  • </nav>
  • </section>
  • </div>
  • <footer id="ft" role="contentinfo">
  • <p>Copyright © 2009 Pádraic Brady</p>
  • <p>Powered by <a href="http://www.survivethedeepend.com">ZFBlog
  • </a></p>
  • </footer>
  • </div>
  • </body>
  • </html>

Since we are using HTML 5, much of the new markup uses the new elements except where they are very clearly needed for the sole purpose of applying the grid layout. For these cases, I've used the normal <div> element. This maintains a logical set of elements where there are only two distinct <section> elements. One for the main content, the other for the left hand sidebar I've introduced. <div> is thus relegated to the boring category of adding CSS "hooks" to the markup for styling - not exactly the cleanest approach but I'm using a CSS Framework so I can live with that.

I've also added roles to a number of elements in accordance with another new standard besides HTML 5, Accessible Rich Internet Applications Suite (WAI–ARIA 1.0), which defines a way to try and make web content and applications more accessible to people with disabilities. It's a small gesture to make while we're adopting HTML 5 and creating a layout from scratch. The standard defines a set of "document landmark roles" which in theory would allow a person using the right software to cut through the web of markup to the parts of the HTML document they want. The roles are therefore very intuitive: banner, main, navigation, contentinfo, complementary, search, etc. There are a lot of these but I'm only using the bare minimum. As an added incentive landmark roles are currently supported by the JAWS 10 screen reader.

In adding a subtitle to the blog, I added a new <hgroup> element. This element groups together related headers and is defined in the HTML 5 specification as follows.

hgroup

The hgroup element is typically used to group a set of one or more h1-h6 elements — to group, for example, a section title and an accompanying subtitle.

Reload the URI http://zfblog.tld in your browser to see what impact this all has.

Basic Blog Index Style

The updated design is beginning, slowly, to look like something we could endure if we possessed endless patience. Let's improve it a bit more, this time by editing /public/css/style.css.

/**
 * Basic Elements
 */
body {
    font-family: Geneva, Verdana, Helvetica, sans-serif;
}
a:link, a:visited {
    color: blue;
    text-decoration: none;
}
a:hover {
    color: red;
    text-decoration: underline;
}

/**
 * HTML 5 Block Display
 *
 * Required by most, if not all, browsers until support is added.
 */
article, aside, dialog, figure, footer, header, hgroup, nav, section {
    display:block;
}

/**
 * Page Elements
 */
header#hd {
    text-align:center;
}
footer#ft {
    text-align: center;
    margin-top: 25px;
    border-top: 1px solid lightgray;
    border-bottom: 1px solid lightgray;
}
section#content {
    border-left: 3px double lightgray;
    padding-left: 10px;
}

/**
 * Headers
 */
h1, h2, h3, h4, h5, h6 {
    Helvetica,Arial,Calibri,sans-serif;
}
header#hd h1 {
    font-size: 200%;
    margin-bottom: 0;
}
header#hd h2 {
    margin-top: 0.4em;
    font-size: 100%;
}

/**
 * Horizontal Header Navigation Menu
 */
header#hd nav {
    border-top: 2px solid #000;
    border-bottom: 2px solid #000;
}
header#hd nav ul {
    list-style: none;
    margin: 0 0 0 20px;
    text-align: left;
}
header#hd nav li
{
    display: inline-block;
    min-width: 50px;
    margin: 0 2px 0 2px;
}
header#hd nav a:link, nav a:visited {
    color: blue;
    display: inline-block;
    height: 20px;
    padding: 5px 1.5em;
    text-decoration: none;
}
header#hd nav a:hover {
    background-color: lightgray;
}

/**
 * Vertical Sidebar Menu/Links
 */
section nav h2 {
    font-size: 120%;
}
section nav ul {
    list-style: none;
    width: 100%;
    margin: 0 auto;
}
section nav ul li
{
    float: left;
    display: inline;
    margin: 0;
}

/**
 * Article related styling
 */
article header {
    margin-bottom: 1em;
}
article header h2 {
    border-bottom: 1px dashed gray;
    font-size: 130%;
    color: green;
    margin-bottom: 0.5em;
}
article header p {
    font-style: italic;
}

Now we have a very basic but acceptable style to work with for now.

Final Blog Index Style

10.10. Conclusion

In this chapter we've covered the basics of creating a simple web design and migrating it to the Zend Framework templating system using Zend_View, Zend_Layout and a number of View Helpers. We'll cover the creation of custom View Helpers in a lot more detail in the chapters to come. We've also covered some of the basics of HTML 5, the upcoming standards update for HTML, and the impact it currently has during implementation on requiring the use of some custom helpers. I have no doubt HTML 5 support in the Zend Framework will materialise in the very near future however, so stay tuned!

In Chapter 11, we'll move on towards the next basic set of functionality. We'll need to display blog entries from our database and, of course, have a means of writing them in the first place! So we will be looking at using our pre-designed domain model and accepting writing new blog entries using forms generated using Zend_Form.

Powered by jQuery Powered by Zend Framework Powered by Nginx Http Server
